TPD3E001DRLR دیتاشیت

TPD3E001DRLR

مشخصات دیتاشیت

نام دیتاشیت TPD3E001DRLR
حجم فایل 101.14 کیلوبایت
نوع فایل pdf
تعداد صفحات 25

دانلود دیتاشیت TPD3E001DRLR

دانلود دیتاشیت

سایر مستندات

TPD3E001 24 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: Texas Instruments TPD3E001DRLR
  • Clamping Voltage@Ipp: -
  • Operating Temperature: -40°C~+85°C@(Ta)
  • Breakdown Voltage (VBR): 11V
  • Peak Pulse Power(Ppp)@8/20us: 90W
  • Junction Capacitance(Cj)@1MHz: -
  • Reverse Stand-Off Voltage (Vrwm): 5.5V
  • Package: SOT(5x3)
  • Manufacturer: Texas Instruments
  • Type: Steering (Rail to Rail)
  • Packaging: Cut Tape (CT)
  • Current - Peak Pulse (10/1000µs): -
  • Base Part Number: TPD3E
  • Package / Case: SOT-553
  • Voltage - Breakdown (Min): 11V
  • Voltage - Clamping (Max) @ Ipp: -
  • Series: -
  • Mounting Type: Surface Mount
  • Capacitance @ Frequency: -
  • Supplier Device Package: SOT-5
  • Unidirectional Channels: 3
  • Applications: General Purpose
  • Part Status: Active
  • Power Line Protection: Yes
  • Power - Peak Pulse: 90W
  • Voltage - Reverse Standoff (Typ): 5.5V (Max)
  • detail: Clamp Ipp Tvs Diode Surface Mount SOT-5
