دیتاشیت TLV75801PDRVR
مشخصات دیتاشیت
| نام دیتاشیت |
TLV75801PDRVR
|
| حجم فایل |
75.116
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
35
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments TLV75801PDRVR
-
Output Type:
Adjustable
-
Output Current:
500mA
-
Output Voltage:
0.55V~5.5V
-
Dropout Voltage:
0.88V@(500mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
6V
-
Operating Temperature:
-40°C~+125°C@(Tj)
-
Quiescent Current (Ground Current):
31uA
-
Package:
DFN-6(2x2)
-
Manufacturer:
Texas Instruments
-
Voltage - Output (Min/Fixed):
0.55V
-
PSRR:
50dB ~ 30dB (1kHz ~ 1MHz)
-
Packaging:
Cut Tape (CT)
-
Base Part Number:
TLV758
-
Package / Case:
6-WDFN Exposed Pad
-
Current - Output:
500mA
-
Control Features:
Enable
-
Voltage Dropout (Max):
0.88V @ 500mA
-
Mounting Type:
Surface Mount
-
Number of Regulators:
1
-
Supplier Device Package:
6-WSON (2x2)
-
Current - Quiescent (Iq):
31µA
-
Protection Features:
Over Temperature, Short Circuit, Soft Start
-
Voltage - Output (Max):
5.5V
-
Series:
-
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Max):
6V
-
detail:
Linear Voltage Regulator IC 1 Output 500mA 6-WSON (2x2)
