دیتاشیت TPD2E2U06DRLR

TPD2E2U06

مشخصات دیتاشیت

نام دیتاشیت TPD2E2U06
حجم فایل 1145.207 کیلوبایت
نوع فایل pdf
تعداد صفحات 21

دانلود دیتاشیت TPD2E2U06

TPD2E2U06 Datasheet

مشخصات

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: Texas Instruments TPD2E2U06DRLR
  • Number of Lines: 2
  • Clamping Voltage@Ipp: 12.4V
  • Operating Temperature: -40°C~+125°C@(Ta)
  • Breakdown Voltage (VBR): 6.5V
  • Peak Pulse Power(Ppp)@8/20us: 85W
  • Junction Capacitance(Cj)@1MHz: -
  • Peak Pulse Current(Ipp)@8/20us: 5.5A@(8/20us)
  • Reverse Stand-Off Voltage (Vrwm): 5.5V
  • Package: SOT-553
  • Manufacturer: Texas Instruments
  • Type: Steering (Rail to Rail)
  • Packaging: Cut Tape (CT)
  • Current - Peak Pulse (10/1000µs): 5.5A (8/20µs)
  • Base Part Number: TPD2E
  • Package / Case: SOT-553
  • Voltage - Breakdown (Min): 6.5V
  • Voltage - Clamping (Max) @ Ipp: 12.4V (Typ)
  • Series: -
  • Mounting Type: Surface Mount
  • Capacitance @ Frequency: -
  • Supplier Device Package: SOT-5
  • Unidirectional Channels: 2
  • Applications: Ethernet
  • Part Status: Active
  • Power Line Protection: Yes
  • Power - Peak Pulse: 85W
  • Voltage - Reverse Standoff (Typ): 5.5V (Max)
  • detail: 12.4V (Typ) Clamp 5.5A (8/20µs) Ipp Tvs Diode Surface Mount SOT-5
