دیتاشیت TPS79318DBVR
مشخصات دیتاشیت
| نام دیتاشیت |
TPS793xx
|
| حجم فایل |
1210.666
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
33
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments TPS79318DBVR
-
Output Type:
Fixed
-
Output Current:
200mA
-
Output Voltage:
1.8V
-
Dropout Voltage:
-
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
5.5V
-
Operating Temperature:
-40°C~+150°C
-
Quiescent Current (Ground Current):
220uA
-
Power Supply Rejection Ratio (PSRR):
70dB@(100Hz),43dB@(100kHz)
-
Package:
SOT-23-5
-
Manufacturer:
Texas Instruments
-
Voltage - Output (Min/Fixed):
1.8V
-
PSRR:
70dB ~ 43dB (100Hz ~ 100kHz)
-
Packaging:
Cut Tape (CT)
-
Base Part Number:
TPS793
-
Package / Case:
SC-74A, SOT-753
-
Current - Output:
200mA
-
Control Features:
Enable
-
Voltage Dropout (Max):
-
-
Mounting Type:
Surface Mount
-
Number of Regulators:
1
-
Supplier Device Package:
SOT-23-5
-
Current - Quiescent (Iq):
220µA
-
Protection Features:
Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
-
Voltage - Output (Max):
-
-
Series:
-
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Max):
5.5V
-
detail:
Linear Voltage Regulator IC 1 Output 200mA SOT-23-5
