TPD6E004RSER دیتاشیت

TPD6E004RSER

مشخصات دیتاشیت

نام دیتاشیت TPD6E004RSER
حجم فایل 82.869 کیلوبایت
نوع فایل pdf
تعداد صفحات 17

مشاهده دیتاشیت TPD6E004RSER

دانلود دیتاشیت

سایر مستندات

TPD6E004 17 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: Texas Instruments TPD6E004RSER
  • Number of Lines: 6
  • Clamping Voltage@Ipp: -
  • Operating Temperature: -40°C~+85°C@(Ta)
  • Breakdown Voltage (VBR): 6V
  • Peak Pulse Power(Ppp)@8/20us: -
  • Junction Capacitance(Cj)@1MHz: -
  • Peak Pulse Current(Ipp)@8/20us: -
  • Reverse Stand-Off Voltage (Vrwm): 5.5V
  • Package: QFN-8(1.5x1.5)
  • Manufacturer: Texas Instruments
  • Type: Steering (Rail to Rail)
  • Current - Peak Pulse (10/1000µs): -
  • Mounting Type: Surface Mount
  • Packaging: Cut Tape (CT)
  • Voltage - Clamping (Max) @ Ipp: -
  • Unidirectional Channels: 6
  • Package / Case: 8-UFQFN
  • Series: -
  • Voltage - Reverse Standoff (Typ): 5.5V (Max)
  • Applications: Ethernet
  • Voltage - Breakdown (Min): 6V
  • Part Status: Active
  • Power - Peak Pulse: -
  • Base Part Number: TPD6E0
  • Power Line Protection: Yes
  • Capacitance @ Frequency: -
  • Supplier Device Package: 8-UQFN (1.5x1.5)
  • detail: Clamp Ipp Tvs Diode Surface Mount 8-UQFN (1.5x1.5)
