دیتاشیت LM78L05ACMX/NOPB

LM78Lxx Datasheet

مشخصات دیتاشیت

نام دیتاشیت LM78Lxx Datasheet
حجم فایل 1492.282 کیلوبایت
نوع فایل pdf
تعداد صفحات 30

دانلود دیتاشیت LM78Lxx Datasheet

LM78Lxx Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments LM78L05ACMX/NOPB
  • Output Type: Fixed
  • Output Current: 100mA
  • Output Voltage: 5V
  • Dropout Voltage: -
  • Output Polarity: Positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 30V
  • Operating Temperature: 0°C~+125°C
  • Quiescent Current (Ground Current): 3mA
  • Power Supply Rejection Ratio (PSRR): 62dB@(120Hz)
  • Package: SOP-8
  • Manufacturer: Texas Instruments
  • Series: -
  • Voltage Dropout (Max): -
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Base Part Number: LM78L05
  • Supplier Device Package: 8-SOIC
  • Current - Output: 100mA
  • Current - Quiescent (Iq): 3mA
  • Part Status: Not For New Designs
  • Voltage - Input (Max): 35V
  • Mounting Type: Surface Mount
  • Control Features: -
  • Protection Features: Over Temperature, Short Circuit
  • Voltage - Output (Min/Fixed): 5V
  • PSRR: 62dB (120Hz)
  • Voltage - Output (Max): -
  • Packaging: Tape & Reel (TR)
  • Output Configuration: Positive
  • Number of Regulators: 1
  • detail: Linear Voltage Regulator IC 1 Output 100mA 8-SOIC
