TLV1117 Datasheet دیتاشیت

TLV1117 Datasheet

مشخصات دیتاشیت

نام دیتاشیت TLV1117 Datasheet
حجم فایل 1669.188 کیلوبایت
نوع فایل pdf
تعداد صفحات 40

دانلود دیتاشیت TLV1117 Datasheet

دانلود دیتاشیت

سایر مستندات

TI TLV1117-33CDCYR 39 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments TLV1117-33CDCYR
  • Output Type: Fixed
  • Output Current: 800mA
  • Output Voltage: 3.3V
  • Dropout Voltage: 1.3V@(800mA)
  • Output Polarity: Positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 15V
  • Operating Temperature: 0°C~+125°C
  • Quiescent Current (Ground Current): 10mA
  • Power Supply Rejection Ratio (PSRR): 75dB@(120Hz)
  • Package: SOT-223
  • Manufacturer: Texas Instruments
  • Number of Regulators: 1
  • Current - Quiescent (Iq): 10mA
  • Base Part Number: TLV111
  • Voltage - Input (Max): 15V
  • Supplier Device Package: SOT-223-4
  • Voltage - Output (Max): -
  • Packaging: Cut Tape (CT)
  • Mounting Type: Surface Mount
  • Protection Features: Over Current, Over Temperature
  • Control Features: -
  • Voltage - Output (Min/Fixed): 3.3V
  • Voltage Dropout (Max): 1.3V @ 800mA
  • Part Status: Active
  • Series: -
  • Current - Output: 800mA
  • PSRR: 75dB (120Hz)
  • Output Configuration: Positive
  • Package / Case: TO-261-4, TO-261AA
  • detail: Linear Voltage Regulator IC 1 Output 800mA SOT-223-4
