TS5A3153 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TS5A3153	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Texas Instruments TS5A3153DCUR
Switch Circuit: -
Package: VSSOP-8
Manufacturer: Texas Instruments
Channel Capacitance (CS(off), CD(off)): 19pF, 36pF
Channel-to-Channel Matching (ΔRon): 50mOhm
Operating Temperature: -40°C ~ 85°C (TA)
Packaging: Cut Tape (CT)
Multiplexer/Demultiplexer Circuit: 2:1
-3db Bandwidth: 97MHz
Charge Injection: 12pC
Current - Leakage (IS(off)) (Max): 20nA
On-State Resistance (Max): 900mOhm
Package / Case: 8-VFSOP (0.091", 2.30mm Width)
Voltage - Supply, Single (V+): 1.65V ~ 5.5V
Switch Time (Ton, Toff) (Max): 16ns, 15ns
Supplier Device Package: 8-VSSOP
Mounting Type: Surface Mount
Base Part Number: TS5A315
Voltage - Supply, Dual (V±): -
Number of Circuits: 1
Crosstalk: -64dB @ 1MHz
Part Status: Active
Series: -
detail: 1 Circuit IC Switch 2:1 900mOhm 8-VSSOP
