TPS22946YZPR Datasheet
Datasheet specifications
|
Datasheet's name
|
TPS22946YZPR
|
|
File size
|
119.483
KB
|
|
File type
|
pdf
|
|
Number of pages
|
36
|
Technical specifications
-
RoHS:
true
-
Category:
Power Supply Chip/Power Distribution Switches
-
Datasheet:
Texas Instruments TPS22946YZPR
-
Input Voltage:
1.62V~5.5V
-
Number of Outputs:
1
-
Resistor On-State:
300mΩ
-
Operating Temperature -:
-40°C~+125°C
-
Package:
BGA
-
Manufacturer:
Texas Instruments
-
Interface:
On/Off
-
Current - Output (Max):
-
-
Operating Temperature:
-40°C ~ 125°C (TJ)
-
Packaging:
Cut Tape (CT)
-
Voltage - Supply (Vcc/Vdd):
Not Required
-
Features:
Auto Restart
-
Fault Protection:
Current Limiting (Fixed), Over Temperature
-
Package / Case:
6-XFBGA, DSBGA
-
Switch Type:
General Purpose
-
Voltage - Load:
1.62V ~ 5.5V
-
Rds On (Typ):
300mOhm
-
Supplier Device Package:
6-DSBGA, 6-WCSP (1.4x0.9)
-
Mounting Type:
Surface Mount
-
Input Type:
Non-Inverting
-
Base Part Number:
TPS229
-
Ratio - Input:Output:
1:1
-
Output Type:
P-Channel
-
Part Status:
Active
-
Series:
-
-
Output Configuration:
High Side
-
detail:
Power Switch/Driver 1:1 P-Channel 6-DSBGA, 6-WCSP (1.4x0.9)
