TS3A44159RGTR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TS3A44159RGTR	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Texas Instruments TS3A44159RGTR
Switch Circuit: -
Package: QFN-16-EP(3x3)
Manufacturer: Texas Instruments
Channel Capacitance (CS(off), CD(off)): 50pF
Channel-to-Channel Matching (ΔRon): 50mOhm
Operating Temperature: -40°C ~ 85°C (TA)
Packaging: Cut Tape (CT)
Multiplexer/Demultiplexer Circuit: 2:1
-3db Bandwidth: 35MHz
Charge Injection: 139pC
Current - Leakage (IS(off)) (Max): 20nA
On-State Resistance (Max): 450mOhm
Package / Case: 16-VFQFN Exposed Pad
Voltage - Supply, Single (V+): 1.65V ~ 4.3V
Switch Time (Ton, Toff) (Max): 23ns, 32ns
Supplier Device Package: 16-QFN (3x3)
Mounting Type: Surface Mount
Base Part Number: TS3A44
Voltage - Supply, Dual (V±): -
Number of Circuits: 4
Crosstalk: -73dB @ 100kHz
Part Status: Active
Series: -
detail: 4 Circuit IC Switch 2:1 450mOhm 16-QFN (3x3)
