LP5951MF-1.5/NOPB دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | LP5951MF-1.5/NOPB |
|---|---|
| حجم فایل | 80.802 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 26 |
دانلود دیتاشیت LP5951MF-1.5/NOPB |
دانلود دیتاشیت |
|---|
سایر مستندات
LP5951 Datasheet 27 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LP5951MF-1.5/NOPB
- Output Type: Fixed
- Output Current: 150mA
- Output Voltage: 1.5V
- Dropout Voltage: 350mV@(150mA)
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 5.5V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 55uA
- Power Supply Rejection Ratio (PSRR): 60dB@(100Hz),50dB@(10kHz)
- Package: SOT-23-5
- Manufacturer: Texas Instruments
- Control Features: Enable
- Base Part Number: LP5951
- Package / Case: SC-74A, SOT-753
- Current - Supply (Max): 70µA
- Part Status: Obsolete
- Current - Output: 150mA
- PSRR: 60dB ~ 50dB (100Hz ~ 10kHz)
- Series: -
- Voltage - Output (Min/Fixed): 1.5V
- Mounting Type: Surface Mount
- Number of Regulators: 1
- Current - Quiescent (Iq): 55µA
- Output Configuration: Positive
- Voltage Dropout (Max): 0.35V @ 150mA
- Supplier Device Package: SOT-23-5
- Protection Features: Over Current, Over Temperature, Short Circuit
- Voltage - Input (Max): 5.5V
- Packaging: Cut Tape (CT)
- Voltage - Output (Max): -
- detail: Linear Voltage Regulator IC 1 Output 150mA SOT-23-5
