TPS78225DDCR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TPS78225DDCR
|
|
حجم فایل
|
93.198
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
29
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments TPS78225DDCR
-
Output Type:
Fixed
-
Output Current:
150mA
-
Output Voltage:
2.5V
-
Dropout Voltage:
250mV@(150mA)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
5.5V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
1.3uA
-
Power Supply Rejection Ratio (PSRR):
40dB@(10Hz),15dB@(1kHz)
-
Package:
SOT-23-5
-
Manufacturer:
Texas Instruments
-
Current - Quiescent (Iq):
1.3µA
-
Voltage - Input (Max):
5.5V
-
Packaging:
Cut Tape (CT)
-
PSRR:
40dB ~ 15dB (10Hz ~ 1kHz)
-
Package / Case:
SOT-23-5 Thin, TSOT-23-5
-
Voltage Dropout (Max):
0.25V @ 150mA
-
Current - Output:
150mA
-
Current - Supply (Max):
8µA
-
Number of Regulators:
1
-
Supplier Device Package:
SOT-23-5
-
Voltage - Output (Max):
-
-
Mounting Type:
Surface Mount
-
Protection Features:
Over Current, Over Temperature, Reverse Polarity
-
Base Part Number:
TPS782
-
Voltage - Output (Min/Fixed):
2.5V
-
Control Features:
Enable
-
Part Status:
Active
-
Series:
-
-
Output Configuration:
Positive
-
detail:
Linear Voltage Regulator IC 1 Output 150mA SOT-23-5
