TS5A12301EYFPR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TS5A12301EYFPR	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Texas Instruments TS5A12301EYFPR
Turn-on time: 225ns
Turn-off time: 215ns
Supply Voltage: 2.25V~5.5V
Switch Circuit: SPDT(SPDT)
Number of Channels: 1
On-State Resistance (Max): 750mΩ
Package: BGA-6
Manufacturer: Texas Instruments
Channel Capacitance (CS(off), CD(off)): 28pF
Channel-to-Channel Matching (ΔRon): 50mOhm
Operating Temperature: -40°C ~ 85°C (TA)
Packaging: Cut Tape (CT)
Multiplexer/Demultiplexer Circuit: 2:1
-3db Bandwidth: 55MHz
Charge Injection: 97pC
Current - Leakage (IS(off)) (Max): 20nA
Package / Case: 6-XFBGA, DSBGA
Voltage - Supply, Single (V+): 2.25V ~ 5.5V
Switch Time (Ton, Toff) (Max): 225ns, 215ns
Supplier Device Package: 6-DSBGA
Mounting Type: Surface Mount
Base Part Number: TS5A123
Voltage - Supply, Dual (V±): -
Number of Circuits: 1
Crosstalk: -63dB @ 1MHz
Part Status: Active
Series: -
detail: 1 Circuit IC Switch 2:1 750mOhm 6-DSBGA
