SN74AC573PWR دیتاشیت

SN74AC573PWR

مشخصات دیتاشیت

نام دیتاشیت SN74AC573PWR
حجم فایل 106.644 کیلوبایت
نوع فایل pdf
تعداد صفحات 23

دانلود دیتاشیت SN74AC573PWR

دانلود دیتاشیت

سایر مستندات

SN54/74AC573 20 pages

مشخصات فنی

  • RoHS: true
  • Series: 74AC
  • Category: Logic ICs/Latches
  • Datasheet: Texas Instruments SN74AC573PWR
  • Logic Type: D-Typelocking Latch
  • Output Type: Tri-State
  • Sink Current: 24mA
  • Source Current: 24mA
  • Supply Voltage: 2V~6V
  • Propagation Delay: 2.5ns
  • OperatingTemperature: -40°C~+85°C
  • Package: TSSOP-20
  • Manufacturer: Texas Instruments
  • Operating Temperature: -40°C ~ 85°C
  • Independent Circuits: 1
  • Current - Output High, Low: 24mA, 24mA
  • Packaging: Cut Tape (CT)
  • Mounting Type: Surface Mount
  • Base Part Number: SN74AC5
  • Circuit: 8:8
  • Package / Case: 20-TSSOP (0.173", 4.40mm Width)
  • Part Status: Active
  • Delay Time - Propagation: 2.5ns
  • Voltage - Supply: 2V ~ 6V
  • Supplier Device Package: 20-TSSOP
  • detail: D-Type Transparent Latch 1 Channel 8:8 IC Tri-State 20-TSSOP
