TPS22860DBVR Datasheet
Datasheet specifications
| Datasheet's name | TPS22860DBVR |
|---|---|
| File size | 68.713 KB |
| File type | |
| Number of pages | 17 |
Download Datasheet TPS22860DBVR |
Download Datasheet |
|---|
Other documentations
Connected Sensors Building Automation Systems Guide 13 pages
TPS22860 18 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/Power Distribution Switches
- Datasheet: Texas Instruments TPS22860DBVR
- Package: SOT-23-6
- Manufacturer: Texas Instruments
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Switch Type: General Purpose
- Number of Outputs: 1
- Ratio - Input:Output: 1:1
- Output Configuration: High Side
- Output Type: -
- Interface: On/Off
- Voltage - Load: 1.65V ~ 5.5V
- Voltage - Supply (Vcc/Vdd): Not Required
- Current - Output (Max): 200mA
- Rds On (Typ): 920mOhm
- Input Type: -
- Features: -
- Fault Protection: -
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Supplier Device Package: SOT-23-6
- Package / Case: SOT-23-6
- Base Part Number: TPS228
- detail: Power Switch/Driver 1:1 200mA SOT-23-6
