LP2951CMM-3.3/NOPB Datasheet

LP2951CMM-3.3/NOPB

Datasheet specifications

Datasheet's name LP2951CMM-3.3/NOPB
File size 112.328 KB
File type pdf
Number of pages 61

Download Datasheet LP2951CMM-3.3/NOPB

Download Datasheet

Other documentations

LP2950,51 55 pages

Technical specifications

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments LP2951CMM-3.3/NOPB
  • Package: VSSOP-8-0.65mm
  • Manufacturer: Texas Instruments
  • Control Features: Enable
  • Base Part Number: LP2951
  • Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
  • Current - Supply (Max): 14mA
  • Part Status: Obsolete
  • Current - Output: 100mA
  • PSRR: -
  • Series: -
  • Voltage - Output (Min/Fixed): 1.235V (3.3V)
  • Mounting Type: Surface Mount
  • Number of Regulators: 1
  • Current - Quiescent (Iq): 120µA
  • Output Configuration: Positive
  • Voltage Dropout (Max): 0.6V @ 100mA
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Supplier Device Package: 8-VSSOP
  • Protection Features: Over Current, Over Temperature, Short Circuit
  • Voltage - Input (Max): 30V
  • Output Type: Adjustable (Fixed)
  • Packaging: Cut Tape (CT)
  • Voltage - Output (Max): 29V
  • detail: Linear Voltage Regulator IC 1 Output 100mA 8-VSSOP
