TPA6130A2RTJR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TPA6130A2RTJR
|
|
حجم فایل
|
100.825
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
39
|
مشخصات فنی
-
RoHS:
true
-
Category:
Operational Amplifier/Comparator/Audio Power OpAmps
-
Datasheet:
Texas Instruments TPA6130A2RTJR
-
Output Power:
290mWx1@16Ω
-
Supply Voltage:
2.5V~5.5V
-
Speaker Channels:
2
-
Operating Temperature:
-40°C~+85°C
-
Type of Power Amplifier:
Class AB
-
Package:
QFN-20-EP(4x4)
-
Manufacturer:
Texas Instruments
-
Type:
Class AB
-
Supplier Device Package:
20-QFN (4x4)
-
Max Output Power x Channels @ Load:
290mW x 1 @ 16Ohm; 138mW x 2 @ 16Ohm
-
Packaging:
Cut Tape (CT)
-
Mounting Type:
Surface Mount
-
Base Part Number:
TPA613
-
Features:
Depop, Differential Inputs, I²C, Mute, Short-Circuit and Thermal Protection, Shutdown, Volume Control
-
Output Type:
Headphones, 2-Channel (Stereo)
-
Package / Case:
20-WFQFN Exposed Pad
-
Part Status:
Active
-
Series:
DirectPath™
-
Voltage - Supply:
2.5V ~ 5.5V
-
detail:
Amplifier IC Headphones, 2-Channel (Stereo) Class AB 20-QFN (4x4)
