LM2931MX-5.0/NOPB دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | LM2931MX-5.0/NOPB |
|---|---|
| حجم فایل | 77.778 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 18 |
دانلود دیتاشیت LM2931MX-5.0/NOPB |
دانلود دیتاشیت |
|---|
سایر مستندات
LM2931 Series 33 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LM2931MX-5.0/NOPB
- Output Type: Fixed
- Output Current: 100mA
- Output Voltage: 5V
- Dropout Voltage: 300mV@(100mA)
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 26V
- Operating Temperature: -40°C~+85°C
- Quiescent Current (Ground Current): 1mA
- Power Supply Rejection Ratio (PSRR): 55dB@(120Hz)
- Package: SOP-8
- Manufacturer: Texas Instruments
- Voltage Dropout (Max): 0.3V @ 100mA
- Current - Supply (Max): 15mA
- Current - Output: 100mA
- Current - Quiescent (Iq): 1mA
- Voltage - Input (Max): 26V
- Base Part Number: LM2931
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Voltage - Output (Max): -
- Output Configuration: Positive
- Series: -
- Supplier Device Package: 8-SOIC
- PSRR: 55dB (120Hz)
- Part Status: Not For New Designs
- Mounting Type: Surface Mount
- Control Features: -
- Protection Features: Over Temperature, Reverse Polarity, Short Circuit
- Voltage - Output (Min/Fixed): 5V
- Number of Regulators: 1
- Packaging: Cut Tape (CT)
- detail: Linear Voltage Regulator IC 1 Output 100mA 8-SOIC
