TPD4E05U06QDQARQ1 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TPD4E05U06QDQARQ1 |
|---|---|
| حجم فایل | 80.299 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 19 |
دانلود دیتاشیت TPD4E05U06QDQARQ1 |
دانلود دیتاشیت |
|---|
سایر مستندات
TPD4E05U06-Q1 23 pages
مشخصات فنی
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
- Polarity: Unidirectional
- Datasheet: Texas Instruments TPD4E05U06QDQARQ1
- Clamping Voltage@Ipp: 14V
- Operating Temperature: -40°C~+125°C@(Ta)
- Breakdown Voltage (VBR): 6.4V
- Peak Pulse Power(Ppp)@8/20us: 40W
- Junction Capacitance(Cj)@1MHz: -
- Peak Pulse Current(Ipp)@8/20us: 2.5A
- Reverse Stand-Off Voltage (Vrwm): 5.5V
- Package: DFN-10(1x2.5)
- Manufacturer: Texas Instruments
- Type: Steering (Rail to Rail)
- Current - Peak Pulse (10/1000µs): 2.5A (8/20µs)
- Mounting Type: Surface Mount
- Packaging: Digi-Reel®
- Voltage - Clamping (Max) @ Ipp: 14V
- Unidirectional Channels: 4
- Package / Case: 10-UFDFN
- Series: Automotive, AEC-Q101
- Voltage - Reverse Standoff (Typ): 5.5V (Max)
- Applications: Automotive, HDMI, USB
- Voltage - Breakdown (Min): 6.4V
- Part Status: Active
- Power - Peak Pulse: 40W
- Base Part Number: TPD4E
- Power Line Protection: Yes
- Capacitance @ Frequency: -
- Supplier Device Package: 10-USON (2.5x1)
- detail: 14V Clamp 2.5A (8/20µs) Ipp Tvs Diode Surface Mount 10-USON (2.5x1)
