دیتاشیت EMIF06-MSD02N16

مشخصات دیتاشیت

دانلود دیتاشیت EMIF06-MSD02N16	EMIF06-MSD02N16 Datasheet

Manufacturer: STMicroelectronics
Series: IPAD™
Packaging: Cut Tape (CT)
Part Status: Active
Type: Low Pass
Filter Order: 2nd
Technology: RC (Pi)
Number of Channels: 6
Center / Cutoff Frequency: -
Attenuation Value: -
Resistance - Channel (Ohms): 45
Values: R = 45Ohms, C = 20pF (Total)
ESD Protection: Yes
Operating Temperature: -30°C ~ 85°C
Applications: Data Lines for Mobile Devices
Voltage - Rated: -
Mounting Type: Surface Mount
Package / Case: 16-UFDFN Exposed Pad
Size / Dimension: 0.138" L x 0.047" W (3.50mm x 1.20mm)
Height: 0.022" (0.55mm)
Base Part Number: EMIF06
detail: RC (Pi) EMI Filter 2nd Order Low Pass 6 Channel R = 45Ohms, C = 20pF (Total) 16-UFDFN Exposed Pad
