L7981ATR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
L7981ATR
|
|
حجم فایل
|
70.095
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
42
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
STMicroelectronics L7981ATR
-
Output Type:
Adjustable
-
Input Voltage:
4.5V~28V
-
Output Voltage:
0.6V~28V
-
Number of Outputs:
1
-
Switching Frequency:
1MHz
-
Output Current (Max):
3A
-
Operating Temperature:
-40°C~+150°C@(TJ)
-
Synchronous Rectification:
NO
-
Package:
SOP-8-EP
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Min):
4.5V
-
Voltage - Input (Max):
28V
-
Voltage - Output (Min/Fixed):
0.6V
-
Voltage - Output (Max):
28V
-
Current - Output:
3A
-
Frequency - Switching:
250kHz ~ 1MHz
-
Synchronous Rectifier:
No
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SOIC (0.154", 3.90mm Width) Exposed Pad
-
Supplier Device Package:
8-HSOP-EP
-
Base Part Number:
L7981
-
detail:
Buck Switching Regulator IC Positive Adjustable 0.6V 1 Output 3A 8-SOIC (0.154", 3.90mm Width) Exposed Pad
