دیتاشیت LP38693MP-3.3/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LP38691(-Q1),LP38693(-Q) |
|---|---|
| حجم فایل | 2108.984 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 35 |
دانلود دیتاشیت LP38691(-Q1),LP38693(-Q) |
LP38691(-Q1),LP38693(-Q) Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LP38693MP-3.3/NOPB
- Output Type: Fixed
- Output Current: 500mA
- Output Voltage: 3.3V
- Dropout Voltage: 550mV@(500mA)
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 10V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 55uA
- Power Supply Rejection Ratio (PSRR): 55dB@(120Hz)
- Package: SOT-223-5
- Manufacturer: Texas Instruments
- Voltage Dropout (Max): 0.55V @ 500mA
- Current - Supply (Max): 100µA
- Current - Output: 500mA
- Current - Quiescent (Iq): 55µA
- Voltage - Input (Max): 10V
- Base Part Number: LP38693
- Package / Case: TO-261-5, TO-261AB
- Voltage - Output (Max): -
- Output Configuration: Positive
- Series: -
- Supplier Device Package: SOT-223-5
- PSRR: 55dB (120Hz)
- Part Status: Not For New Designs
- Mounting Type: Surface Mount
- Control Features: Enable
- Protection Features: Over Temperature
- Voltage - Output (Min/Fixed): 3.3V
- Number of Regulators: 1
- Packaging: Cut Tape (CT)
- detail: Linear Voltage Regulator IC 1 Output 500mA SOT-223-5
