LM3525MX-L/NOPB Datasheet
Datasheet specifications
| Datasheet's name | LM3525MX-L/NOPB |
|---|---|
| File size | 89.015 KB |
| File type | |
| Number of pages | 17 |
Download Datasheet LM3525MX-L/NOPB |
Download Datasheet |
|---|
Other documentations
LM3525 19 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/Power Distribution Switches
- Datasheet: Texas Instruments LM3525MX-L/NOPB
- Input Voltage: 2.7V~5.5V
- Output Current: 500mA
- Number of Outputs: 1
- Resistor On-State: 80mΩ
- Operating Temperature -: -40°C~+85°C
- Package: SOP-8
- Manufacturer: Texas Instruments
- Voltage - Supply (Vcc/Vdd): Not Required
- Switch Type: USB Switch
- Base Part Number: LM3525
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Features: Status Flag
- Voltage - Load: 2.7V ~ 5.5V
- Series: -
- Mounting Type: Surface Mount
- Output Type: P-Channel
- Part Status: Obsolete
- Rds On (Typ): 80mOhm
- Output Configuration: High Side
- Operating Temperature: -40°C ~ 85°C (TA)
- Fault Protection: Current Limiting (Fixed), Over Temperature, UVLO
- Supplier Device Package: 8-SOIC
- Input Type: Non-Inverting
- Current - Output (Max): 500mA
- Interface: On/Off
- Packaging: Cut Tape (CT)
- Ratio - Input:Output: 1:1
- detail: Power Switch/Driver 1:1 P-Channel 500mA 8-SOIC
