S2-LPQTR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | S2-LPQTR |
|---|---|
| حجم فایل | 63.776 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 90 |
دانلود دیتاشیت S2-LPQTR |
دانلود دیتاشیت |
|---|
سایر مستندات
S2-LP Datasheet 90 pages
S2-LP Errata 5 pages
مشخصات فنی
- RoHS: true
- Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
- Data Rate: 500Kbps
- Datasheet: STMicroelectronics S2-LPQTR
- Interface: SPI,UART
- Applications: General-purpose ISM<1GHz
- Receive Current: 8mA
- Operating Voltage: 1.8V~3.6V
- Operating Temperature: -40°C~+85°C
- Current Of Transmitting: 27mA
- Package: QFN-24-EP(4x4)
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: TxRx Only
- RF Family/Standard: General ISM < 1GHz
- Protocol: SIGFOX™, Wireless M-Bus
- Modulation: 2GFSK, 4GFSK, ASK, OOK
- Data Rate (Max): 500kbps
- Power - Output: 10dBm
- Sensitivity: -130dBm
- Memory Size: -
- Serial Interfaces: SPI, UART
- GPIO: 4
- Voltage - Supply: 1.8V ~ 3.6V
- Current - Receiving: 8mA
- Current - Transmitting: 27mA
- Mounting Type: Surface Mount
- Package / Case: 24-VFQFN Exposed Pad
- Supplier Device Package: 24-QFN (4x4)
- Base Part Number: S2-LP
- detail: IC RF TxRx Only General ISM < 1GHz SIGFOX™, Wireless M-Bus 24-VFQFN Exposed Pad
