دیتاشیت L78L05ABUTR
مشخصات دیتاشیت
| نام دیتاشیت |
L78L Datasheet
|
| حجم فایل |
1631.68
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
45
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
STMicroelectronics L78L05ABUTR
-
Output Type:
Fixed
-
Output Current:
100mA
-
Output Voltage:
5V
-
Dropout Voltage:
1.7V@(40mA)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
30V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
5.5mA
-
Power Supply Rejection Ratio (PSRR):
49dB@(120Hz)
-
Package:
SOT-89
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Voltage - Input (Max):
30V
-
Voltage - Output (Min/Fixed):
5V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
-
-
Current - Output:
100mA
-
Current - Quiescent (Iq):
5.5mA
-
Current - Supply (Max):
6mA
-
PSRR:
49dB (120Hz)
-
Control Features:
-
-
Protection Features:
Over Current, Over Temperature, Short Circuit
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-243AA
-
Supplier Device Package:
SOT-89-3
-
Base Part Number:
L78L05
-
detail:
Linear Voltage Regulator IC 1 Output 100mA SOT-89-3
