UCC28880DR Datasheet
Datasheet specifications
| Datasheet's name | UCC28880DR |
|---|---|
| File size | 94.058 KB |
| File type | |
| Number of pages | 41 |
Download Datasheet UCC28880DR |
Download Datasheet |
|---|
Other documentations
UCC28880 Datasheet 41 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/AC-DC Controllers & Regulators
- Topology: Step-down;Step-down-Boost;Flyback
- Datasheet: Texas Instruments UCC28880DR
- Duty Cycle: 55%
- Supply Voltage: 3.6V~5V
- Output Isolation: Non-Insulated
- Breakdown Voltage: 700V
- Switching Frequency: 62kHz
- Operating Temperature: -40°C~+105°C@(Ta)
- Package: SOP-7
- Manufacturer: Texas Instruments
- Voltage - Breakdown: 700V
- Base Part Number: UCC288
- Supplier Device Package: 7-SOIC
- Packaging: Cut Tape (CT)
- Package / Case: 8-SOIC (0.154", 3.90mm Width), 7 Leads
- Mounting Type: Surface Mount
- Voltage - Start Up: 3.9V
- Fault Protection: Current Limiting, Over Load, Over Temperature, Short Circuit
- Voltage - Supply (Vcc/Vdd): 3.6V ~ 5V
- Part Status: Active
- Series: -
- Internal Switch(s): Yes
- Frequency - Switching: 62kHz
- Control Features: -
- detail: Converter Offline Buck, Buck-Boost, Flyback Topology 62kHz 7-SOIC
