دیتاشیت TPS73525DRVR
مشخصات دیتاشیت
| نام دیتاشیت | TPS73525DRVR |
|---|---|
| حجم فایل | 74.335 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 39 |
TPS73525DRVR |
دانلود دیتاشیت |
|---|
سایر مستندات
TPS735xx Datasheet 38 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments TPS73525DRVR
- Output Current: 500mA
- Output Voltage: 2.5V
- Dropout Voltage: 0.5V@(500mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 6.5V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 65uA
- Package: DFN-6(2x2)
- Manufacturer: Texas Instruments
- Series: -
- Supplier Device Package: 6-WSON (2x2)
- Voltage - Output (Min/Fixed): 2.5V
- Mounting Type: Surface Mount
- Current - Output: 500mA
- Voltage - Input (Max): 6.5V
- Base Part Number: TPS735
- Voltage - Output (Max): -
- PSRR: 66dB ~ 22dB (100Hz ~ 100kHz)
- Current - Quiescent (Iq): 65µA
- Packaging: Cut Tape (CT)
- Output Type: Fixed
- Control Features: Enable
- Package / Case: 6-WDFN Exposed Pad
- Number of Regulators: 1
- Protection Features: Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
- Output Configuration: Positive
- Voltage Dropout (Max): 0.5V @ 500mA
- Part Status: Active
- detail: Linear Voltage Regulator IC 1 Output 500mA 6-WSON (2x2)
