دیتاشیت LM317MDTX/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM117/317-N Datasheet |
|---|---|
| حجم فایل | 6174.891 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 51 |
دانلود دیتاشیت LM117/317-N Datasheet |
LM117/317-N Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LM317MDTX/NOPB
- Output Type: Adjustable
- Output Current: 500mA
- Output Voltage: 1.25V~37V
- Dropout Voltage: -
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 40V
- Operating Temperature: 0°C~+125°C@(Tj)
- Quiescent Current (Ground Current): 10mA
- Package: TO-252
- Manufacturer: Texas Instruments
- Series: -
- Supplier Device Package: TO-252-3
- Voltage - Output (Min/Fixed): 1.25V
- Mounting Type: Surface Mount
- Current - Output: 500mA
- Voltage - Input (Max): 37V
- Base Part Number: LM317
- Voltage - Output (Max): 37V
- PSRR: 80dB ~ 65dB (120Hz)
- Packaging: Cut Tape (CT)
- Control Features: -
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Number of Regulators: 1
- Protection Features: Over Current, Over Temperature, Short Circuit
- Output Configuration: Positive
- Voltage Dropout (Max): -
- Part Status: Active
- detail: Linear Voltage Regulator IC 1 Output 500mA TO-252-3
