STB13007DT4 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
STB13007DT4
|
|
حجم فایل
|
55.272
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
9
|
مشخصات فنی
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
-
Datasheet:
STMicroelectronics STB13007DT4
-
Transistor Type:
NPN
-
Operating Temperature:
+150°C@(Tj)
-
Collector Current (Ic):
8A
-
Power Dissipation (Pd):
80W
-
Transition Frequency (fT):
-
-
DC Current Gain (hFE@Ic,Vce):
8@5A,5V
-
Collector Cut-Off Current (Icbo):
100uA
-
Collector-Emitter Breakdown Voltage (Vceo):
400V
-
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib):
3V@5A,1A
-
Package:
D2PAK
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Current - Collector (Ic) (Max):
8A
-
Voltage - Collector Emitter Breakdown (Max):
400V
-
Vce Saturation (Max) @ Ib, Ic:
3V @ 1A, 5A
-
Current - Collector Cutoff (Max):
100µA
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
8 @ 5A, 5V
-
Power - Max:
80W
-
Frequency - Transition:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
-
Supplier Device Package:
D2PAK
-
Base Part Number:
STB13007
-
detail:
Bipolar (BJT) Transistor NPN 400V 8A 80W Surface Mount D2PAK
