دیتاشیت STPS30SM100SG-TR
مشخصات دیتاشیت
| نام دیتاشیت |
STPS30SM100S
|
| حجم فایل |
339.247
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
14
|
مشخصات
-
RoHS:
true
-
Category:
Diodes/Schottky Barrier Diodes (SBD)
-
Datasheet:
STMicroelectronics STPS30SM100SG-TR
-
Diode Configuration:
Single
-
Reverse Voltage (Vr):
100V
-
Forward Voltage (Vf@If):
780mV@30A
-
Reverse Leakage Current (Ir):
45uA@100V
-
Average Rectified Current (Io):
30A
-
Package:
D2PAK
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Schottky
-
Voltage - DC Reverse (Vr) (Max):
100V
-
Current - Average Rectified (Io):
30A
-
Voltage - Forward (Vf) (Max) @ If:
870mV @ 30A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
45µA @ 100V
-
Capacitance @ Vr, F:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
-
Supplier Device Package:
D²PAK
-
Operating Temperature - Junction:
150°C (Max)
-
Base Part Number:
STPS30
-
detail:
Diode Schottky 100V 30A Surface Mount D²PAK
