دیتاشیت LP5912-3.3DRVT
مشخصات دیتاشیت
| نام دیتاشیت | LP5912 Datasheet |
|---|---|
| حجم فایل | 3153.037 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 36 |
دانلود دیتاشیت LP5912 Datasheet |
LP5912 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LP5912-3.3DRVT
- Output Type: Fixed
- Output Current: 500mA
- Output Voltage: 3.3V
- Dropout Voltage: 250mV@(500mA)
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 6.5V
- Operating Temperature: -40°C~+125°C@(Tj)
- Quiescent Current (Ground Current): 55uA
- Power Supply Rejection Ratio (PSRR): 40dB@(100kHz)
- Package: DFN-6(2x2)
- Manufacturer: Texas Instruments
- Series: -
- Control Features: Enable, Power Good, Soft Start
- Voltage - Output (Max): -
- Current - Quiescent (Iq): 55µA
- Supplier Device Package: 6-WSON (2x2)
- Voltage Dropout (Max): 0.18V @ 500mA
- Number of Regulators: 1
- PSRR: 80dB ~ 40db (100Hz ~ 100kHz)
- Mounting Type: Surface Mount
- Voltage - Output (Min/Fixed): 3.3V
- Current - Output: 500mA
- Voltage - Input (Max): 6.5V
- Current - Supply (Max): 600µA
- Protection Features: Over Temperature, Reverse Polarity, Short Circuit
- Packaging: Cut Tape (CT)
- Base Part Number: LP5912
- Package / Case: 6-WDFN Exposed Pad
- Part Status: Active
- Output Configuration: Positive
- detail: Linear Voltage Regulator IC 1 Output 500mA 6-WSON (2x2)
