دیتاشیت TPS61021ADSGT

مشخصات دیتاشیت

دانلود دیتاشیت TPS61021A Datasheet	TPS61021A Datasheet Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: boost converterType
Topology: Boost
Datasheet: Texas Instruments TPS61021ADSGT
Output Type: Adjustable
Input Voltage: 0.5V~4.4V
Output Voltage: 1.8V~4V
Number of Outputs: 1
Switching Frequency: 2MHz
Output Current (Max): 3A
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: Yes
Package: DFN-8(2x2)
Manufacturer: Texas Instruments
Series: -
Supplier Device Package: 8-WSON (2x2)
Voltage - Output (Min/Fixed): 1.8V
Voltage - Input (Min): 0.5V
Mounting Type: Surface Mount
Output Configuration: Positive
Package / Case: 8-WFDFN Exposed Pad
Voltage - Output (Max): 4V
Synchronous Rectifier: Yes
Base Part Number: TPS610
Packaging: Cut Tape (CT)
Frequency - Switching: 2MHz
Current - Output: 3A (Switch)
Voltage - Input (Max): 4.4V
Part Status: Active
detail: Boost Switching Regulator IC Positive Adjustable 1.8V 1 Output 3A (Switch) 8-WFDFN Exposed Pad
