دیتاشیت TPS60500DGSR

مشخصات دیتاشیت

دانلود دیتاشیت TPS60500-03 Datasheet	TPS60500-03 Datasheet Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: -
Datasheet: Texas Instruments TPS60500DGSR
Output Type: Adjustable
Input Voltage: 1.8V~6.5V
Output Voltage: 0.8V~3.3V
Number of Outputs: 1
Switching Frequency: 800kHz
Output Current (Max): 250mA
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: NO
Package: MSOP-10
Manufacturer: Texas Instruments
Series: -
Supplier Device Package: 10-VSSOP
Voltage - Output (Min/Fixed): 0.8V
Voltage - Input (Min): 1.8V
Mounting Type: Surface Mount
Output Configuration: Positive
Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
Voltage - Output (Max): 3.3V
Synchronous Rectifier: No
Base Part Number: TPS605
Packaging: Cut Tape (CT)
Frequency - Switching: 800kHz
Current - Output: 250mA
Voltage - Input (Max): 6.5V
Part Status: Active
detail: Charge Pump Switching Regulator IC Positive Adjustable 0.8V 1 Output 250mA 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
