دیتاشیت TPS76201DBVR
مشخصات دیتاشیت
| نام دیتاشیت |
TPS76201
|
| حجم فایل |
967.571
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
17
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments TPS76201DBVR
-
Output Type:
Adjustable
-
Output Current:
100mA
-
Output Voltage:
0.7V~5.5V
-
Dropout Voltage:
-
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
10V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
30uA
-
Power Supply Rejection Ratio (PSRR):
60dB@(1kHz)
-
Package:
SOT-23-5
-
Manufacturer:
Texas Instruments
-
Series:
-
-
Supplier Device Package:
SOT-23-5
-
Voltage - Output (Min/Fixed):
0.7V
-
Mounting Type:
Surface Mount
-
Current - Output:
100mA
-
Voltage - Input (Max):
10V
-
Base Part Number:
TPS762
-
Voltage - Output (Max):
5.5V
-
PSRR:
60dB (1kHz)
-
Current - Quiescent (Iq):
30µA
-
Packaging:
Cut Tape (CT)
-
Control Features:
Enable
-
Package / Case:
SC-74A, SOT-753
-
Number of Regulators:
1
-
Protection Features:
Over Current, Over Temperature, Reverse Polarity
-
Output Configuration:
Positive
-
Voltage Dropout (Max):
-
-
Part Status:
Active
-
detail:
Linear Voltage Regulator IC 1 Output 100mA SOT-23-5
