دیتاشیت OPA2170AIDR
مشخصات دیتاشیت
| نام دیتاشیت | OPA170,2170,4170 |
|---|---|
| حجم فایل | 3560.882 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 55 |
دانلود دیتاشیت OPA170,2170,4170 |
OPA170,2170,4170 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/Operational Amplifier
- Datasheet: Texas Instruments OPA2170AIDR
- -3db Bandwidth: -
- Output Current: 20mA
- Supply Current: 110uA
- Number of Circuits: 2
- Operating Temperature: -40°C~+125°C
- Current - Input Bias(Ib): 8pA
- Gain Bandwidth Product(GBP): 1.2MHz
- Package: SOIC-8
- Manufacturer: Texas Instruments
- Base Part Number: OPA217
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Gain Bandwidth Product: 1.2MHz
- Series: -
- Slew Rate: 0.4V/µs
- Current - Supply: 110µA
- Voltage - Supply, Single/Dual (±): 2.7V ~ 36V, ±1.35V ~ 18V
- Current - Input Bias: 8pA
- Packaging: Cut Tape (CT)
- Mounting Type: Surface Mount
- Part Status: Active
- Voltage - Input Offset: 250µV
- Amplifier Type: General Purpose
- Output Type: Rail-to-Rail
- Current - Output / Channel: 20mA
- Supplier Device Package: 8-SOIC
- detail: General Purpose Amplifier 2 Circuit Rail-to-Rail 8-SOIC
