TPL0102-100RUCR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TPL0102-100RUCR |
|---|---|
| حجم فایل | 77.223 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 46 |
دانلود دیتاشیت TPL0102-100RUCR |
دانلود دیتاشیت |
|---|
سایر مستندات
Analog Signal Chain Guide 11 pages
TPL0102 46 pages
مشخصات فنی
- RoHS: true
- Category: ADC/DAC/Data Conversion/Digital Potentiometers
- Datasheet: Texas Instruments TPL0102-100RUCR
- Precision: ±20%
- Interface Type: I2C
- Number of Taps: 256
- Supply Voltage: 2.7V~5.5V;2.25V~2.75V
- Number of Channels: 2
- Operating Temperature: -40°C~+85°C
- Resistance Value (Ohms): 100kΩ
- Temperature Coefficient (Typ): 92ppm/°C
- Package: QFN-14(2x2)
- Manufacturer: Texas Instruments
- Base Part Number: TPL010
- Interface: I²C
- Features: Selectable Address
- Resistance - Wiper (Ohms) (Typ): 25
- Tolerance: ±20%
- Resistance (Ohms): 100k
- Packaging: Cut Tape (CT)
- Supplier Device Package: 14-QFN (2x2)
- Voltage - Supply: 2.7V ~ 5.5V, ±2.25V ~ 2.75V
- Part Status: Active
- Series: -
- Configuration: Potentiometer
- Mounting Type: Surface Mount
- Number of Circuits: 2
- Taper: Linear
- Memory Type: Non-Volatile
- Package / Case: 14-XFQFN
- detail: Digital Potentiometer 100k Ohm 2 Circuit 256 Taps I²C Interface 14-QFN (2x2)
