UA7805CKCS دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
UA7805CKCS
|
|
حجم فایل
|
71.697
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
27
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments UA7805CKCS
-
Output Current:
1.5A
-
Output Voltage:
5V
-
Dropout Voltage:
2V@(1A)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
25V
-
Operating Temperature:
0°C~+125°C
-
Package:
TO-220
-
Manufacturer:
Texas Instruments
-
Series:
-
-
Voltage Dropout (Max):
2V @ 1A
-
Package / Case:
TO-220-3
-
Base Part Number:
UA780
-
Supplier Device Package:
TO-220-3
-
Current - Output:
1.5A
-
PSRR:
78dB ~ 68dB (120Hz)
-
Part Status:
Obsolete
-
Voltage - Input (Max):
25V
-
Mounting Type:
Through Hole
-
Control Features:
-
-
Protection Features:
Over Temperature, Reverse Polarity
-
Voltage - Output (Min/Fixed):
5V
-
Voltage - Output (Max):
-
-
Packaging:
Tube
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Output Type:
Fixed
-
detail:
Linear Voltage Regulator IC 1 Output 1.5A TO-220-3
