SN74LVC1G32MDCKREP دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SN74LVC1G32MDCKREP |
|---|---|
| حجم فایل | 100.146 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 16 |
دانلود دیتاشیت SN74LVC1G32MDCKREP |
دانلود دیتاشیت |
|---|
سایر مستندات
SN74LVC1G32-EP 16 pages
مشخصات فنی
- RoHS: true
- Series: 74LVC
- Category: Logic ICs/Gates
- Datasheet: Texas Instruments SN74LVC1G32MDCKREP
- Sink Current: 32mA
- Source Current: 32mA
- Supply Voltage: 1.65V~5.5V
- Logic Gate Type: ORGate
- Number of Channels: 1
- Low Level Range (VIL): 0.7V~0.8V
- Operating Temperature: -55°C~+125°C
- High Level Range (VIH): 1.7V~2V
- Propagation Delay Time: 4.5ns@5V,50pF
- Quiescent Current (Max): 10uA
- Package: SC-70-5
- Manufacturer: Texas Instruments
- Package / Case: 5-TSSOP, SC-70-5, SOT-353
- Base Part Number: SN74LVC1G
- Supplier Device Package: SC-70-5
- Number of Inputs: 2
- Features: -
- Logic Level - Low: 0.7V ~ 0.8V
- Max Propagation Delay @ V, Max CL: 4.5ns @ 5V, 50pF
- Packaging: Cut Tape (CT)
- Mounting Type: Surface Mount
- Voltage - Supply: 1.65V ~ 5.5V
- Part Status: Active
- Logic Type: OR Gate
- Logic Level - High: 1.7V ~ 2V
- Number of Circuits: 1
- Current - Quiescent (Max): 10µA
- Current - Output High, Low: 32mA, 32mA
- detail: OR Gate IC 1 Channel SC-70-5
