دیتاشیت TPS62172DSGT
مشخصات دیتاشیت
| نام دیتاشیت | TPS62170,71,72,73 |
|---|---|
| حجم فایل | 2998.484 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 37 |
دانلود دیتاشیت TPS62170,71,72,73 |
TPS62170,71,72,73 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Datasheet: Texas Instruments TPS62172DSGT
- Package: DFN-8(2x2)
- Manufacturer: Texas Instruments
- Topology: Buck
- Frequency - Switching: 2.25MHz
- Number of Outputs: 1
- Package / Case: 8-WFDFN Exposed Pad
- Supplier Device Package: 8-WSON (2x2)
- Voltage - Output (Min/Fixed): 3.3V
- Current - Output: 500mA
- Operating Temperature: -40°C ~ 85°C (TA)
- Output Configuration: Positive
- Packaging: Cut Tape (CT)
- Function: Step-Down
- Part Status: Active
- Voltage - Output (Max): -
- Series: DCS-Control™
- Mounting Type: Surface Mount
- Voltage - Input (Max): 17V
- Output Type: Fixed
- Base Part Number: TPS621
- Voltage - Input (Min): 3V
- Synchronous Rectifier: Yes
- detail: Buck Switching Regulator IC Positive Fixed 3.3V 1 Output 500mA 8-WFDFN Exposed Pad
