TPS79501DRBR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TPS79501DRBR	دانلود دیتاشیت

TPS795xx 34 pages

RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: Texas Instruments TPS79501DRBR
Output Type: Adjustable
Output Current: 500mA
Output Voltage: 1.2V~5.5V
Dropout Voltage: -
Output Polarity: Positive
Number of Outputs: 1
Maximum Input Voltage: 5.5V
Power Supply Rejection Ratio (PSRR): 59dB@(100Hz),39dB@(100kHz)
Package: DFN-8(3x3)
Manufacturer: Texas Instruments
Voltage - Output (Min/Fixed): 1.2V
Voltage Dropout (Max): -
Package / Case: 8-VDFN Exposed Pad
Control Features: Enable
Supplier Device Package: 8-SON (3x3)
Current - Output: 500mA
Operating Temperature: -40°C ~ 125°C
Voltage - Output (Max): 5.5V
Packaging: Cut Tape (CT)
Mounting Type: Surface Mount
Part Status: Active
Output Configuration: Positive
Series: -
Base Part Number: TPS795
Voltage - Input (Max): 5.5V
Protection Features: Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
PSRR: 59dB ~ 39dB (100Hz ~ 100kHz)
Number of Regulators: 1
Current - Quiescent (Iq): 385µA
detail: Linear Voltage Regulator IC 1 Output 500mA 8-SON (3x3)
