دیتاشیت STM32H753ZIT6
مشخصات دیتاشیت
| نام دیتاشیت | STM32H753xI Datasheet |
|---|---|
| حجم فایل | 4892.127 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 356 |
دانلود دیتاشیت STM32H753xI Datasheet |
STM32H753xI Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- EEPROM: -
- CPU Core: ARM-MSeries
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 1MB
- Watchdog: -
- ADC (Bit): 16bit
- DAC (Bit): 12bit
- Datasheet: STMicroelectronics STM32H753ZIT6
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 480MHz
- GPIO Ports Number: 114
- Low-Voltage Detect: -
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: DMA;LCD/LED Driver
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 2MB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 1.62V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: LQFP-144(20x20)
- Manufacturer: STMicroelectronics
- Series: STM32H7
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM® Cortex®-M7
- Core Size: 32-Bit
- Speed: 480MHz
- Connectivity: CANbus, EBI/EMI, Ethernet, I²C, IrDA, LINbus, MDIO, MMC/SD/SDIO, QSPI, SAI, SPDIF, SPI, SWPMI, UART/USART, USB OTG
- Peripherals: Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT
- Number of I/O: 114
- Program Memory Size: 2MB (2M x 8)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 1.62V ~ 3.6V
- Data Converters: A/D 36x16b; D/A 2x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 144-LQFP
- Supplier Device Package: 144-LQFP (20x20)
- Base Part Number: STM32H753
- detail: ARM® Cortex®-M7 STM32H7 Microcontroller IC 32-Bit 480MHz 2MB (2M x 8) FLASH 144-LQFP (20x20)
