دیتاشیت TPS40210DGQR

مشخصات دیتاشیت

دانلود دیتاشیت TPS40210, TPS40211	TPS40210, TPS40211 Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Controllers
Function: boost converterType;Buck-boost type
Topology: Boost;Flyback;SEPIC
Datasheet: Texas Instruments TPS40210DGQR
Input Voltage: 4.5V~52V
Duty Cycle (Max): -
Number of Outputs: 1
Switching Frequency: 1MHz
Output Current (Max): 6A
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: NO
Package: MSOP-10-EP
Manufacturer: Texas Instruments
Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad
Control Features: Enable, Frequency Control, Soft Start
Output Configuration: Positive
Packaging: Cut Tape (CT)
Supplier Device Package: 10-MSOP-PowerPad
Part Status: Active
Base Part Number: TPS402
Output Type: Transistor Driver
Output Phases: 1
Synchronous Rectifier: No
Voltage - Supply (Vcc/Vdd): 4.5V ~ 52V
Frequency - Switching: 35kHz ~ 1MHz
Series: -
Mounting Type: Surface Mount
Clock Sync: Yes
Serial Interfaces: -
detail: Boost, Flyback, SEPIC Regulator Positive Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 10-MSOP-PowerPad
