TPS73601DBVRG4 Datasheet

TPS736xx

Datasheet specifications

Datasheet's name TPS736xx
File size 1717.382 KB
File type pdf
Number of pages 42

Download Datasheet TPS736xx

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Voltage Dropout (Max): 0.2V @ 400mA
  • Package / Case: SC-74A, SOT-753
  • Control Features: Enable
  • Current - Output: 400mA
  • Operating Temperature: -40°C ~ 125°C
  • Output Configuration: Positive
  • Voltage - Output (Min/Fixed): 1.2V
  • Supplier Device Package: SOT-23-5
  • Part Status: Active
  • Manufacturer: Texas Instruments
  • Current - Supply (Max): 1mA
  • Base Part Number: TPS736
  • Output Type: Adjustable
  • PSRR: 58dB ~ 37dB (100Hz ~ 10kHz)
  • Protection Features: Over Current, Over Temperature, Reverse Polarity
  • Packaging: Cut Tape (CT)
  • Voltage - Output (Max): 5.5V
  • Voltage - Input (Max): 5.5V
  • Series: -
  • Mounting Type: Surface Mount
  • Current - Quiescent (Iq): 550µA
  • Number of Regulators: 1
  • detail: Linear Voltage Regulator IC 1 Output 400mA SOT-23-5
