DRV8830DGQR دیتاشیت

DRV8830DGQR

مشخصات دیتاشیت

نام دیتاشیت DRV8830DGQR
حجم فایل 93.35 کیلوبایت
نوع فایل pdf
تعداد صفحات 31

دانلود دیتاشیت DRV8830DGQR

دانلود دیتاشیت

سایر مستندات

DRV8830 32 pages

DRV8830DGQR 23 pages

مشخصات فنی

  • RoHS: true
  • Type: Brush DC Motor
  • Category: Power Supply Chip/Motor Driver ICs
  • Datasheet: Texas Instruments DRV8830DGQR
  • Interface: I2C
  • Output Current: 1A
  • Supply Voltage: 2.75V~6.8V
  • Operating Temperature: -40°C~+150°C@(Tj)
  • Package: MSOP-10-EP
  • Manufacturer: Texas Instruments
  • Base Part Number: DRV8830
  • Motor Type - Stepper: Bipolar
  • Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad
  • Applications: Battery Powered
  • Supplier Device Package: 10-MSOP-PowerPad
  • Current - Output: 1A
  • Voltage - Load: 2.75V ~ 6.8V
  • Output Configuration: Half Bridge (2)
  • Packaging: Cut Tape (CT)
  • Function: Driver - Fully Integrated, Control and Power Stage
  • Step Resolution: -
  • Part Status: Active
  • Series: -
  • Mounting Type: Surface Mount
  • Motor Type - AC, DC: Brushed DC
  • Voltage - Supply: 2.75V ~ 6.8V
  • Technology: Power MOSFET
  • detail: Bipolar Motor Driver Power MOSFET I²C 10-MSOP-PowerPad
