TPS63050RMWR 数据手册
其他文档
TPS63050,TPS63051 Datasheet 36 pages
技术规格
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Buck-boost type
- Topology: Step-down-Boost
- Datasheet: Texas Instruments TPS63050RMWR
- Output Type: Adjustable
- Input Voltage: 2.5V~5.5V
- Output Voltage: 2.5V~5.5V
- Number of Outputs: 1
- Switching Frequency: 2.5MHz
- Output Current (Max): 500mA
- Operating Temperature: -40°C~+85°C@(TA)
- Synchronous Rectification: Yes
- Package: VFQFN-12(2.5x2.5)
- Manufacturer: Texas Instruments
- Frequency - Switching: 2.5MHz
- Package / Case: 12-VFQFN
- Supplier Device Package: 12-VQFN-HR (2.5x2.5)
- Voltage - Output (Min/Fixed): 2.5V
- Current - Output: 500mA
- Output Configuration: Positive
- Packaging: Cut Tape (CT)
- Part Status: Active
- Voltage - Output (Max): 5.5V
- Series: -
- Mounting Type: Surface Mount
- Voltage - Input (Max): 5.5V
- Base Part Number: TPS630
- Voltage - Input (Min): 2.5V
- Synchronous Rectifier: Yes
- detail: Buck-Boost Switching Regulator IC Positive Adjustable 2.5V 1 Output 500mA 12-VFQFN
