دیتاشیت TPS62046DGQR
مشخصات دیتاشیت
| نام دیتاشیت | TPS62046DGQR |
|---|---|
| حجم فایل | 98.979 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 30 |
TPS62046DGQR |
دانلود دیتاشیت |
|---|
سایر مستندات
TPS62040/42/43/44/46 30 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Texas Instruments TPS62046DGQR
- Output Type: Fixed
- Input Voltage: 2.5V~6V
- Output Voltage: 3.3V
- Number of Outputs: 1
- Switching Frequency: 1.25MHz
- Output Current (Max): 1.2A
- Operating Temperature: -40°C~+85°C@(TA)
- Synchronous Rectification: Yes
- Package: MSOP-10-EP
- Manufacturer: Texas Instruments
- Frequency - Switching: 1.25MHz
- Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad
- Supplier Device Package: 10-MSOP-PowerPad
- Voltage - Output (Min/Fixed): 3.3V
- Current - Output: 1.2A
- Output Configuration: Positive
- Packaging: Cut Tape (CT)
- Part Status: Active
- Voltage - Output (Max): -
- Series: -
- Mounting Type: Surface Mount
- Voltage - Input (Max): 6V
- Base Part Number: TPS620
- Voltage - Input (Min): 2.5V
- Synchronous Rectifier: Yes
- detail: Buck Switching Regulator IC Positive Fixed 3.3V 1 Output 1.2A 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad
