دیتاشیت LM2937IMP-12/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM2937 Datasheet |
|---|---|
| حجم فایل | 2140.15 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 31 |
دانلود دیتاشیت LM2937 Datasheet |
LM2937 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LM2937IMP-12/NOPB
- Output Type: Fixed
- Output Current: 400mA
- Output Voltage: 12V
- Dropout Voltage: 1V@(50mA)
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 26V
- Operating Temperature: -40°C~+85°C
- Quiescent Current (Ground Current): 2mA
- Power Supply Rejection Ratio (PSRR): -
- Package: SOT-223
- Manufacturer: Texas Instruments
- Voltage Dropout (Max): 1V @ 50mA
- Current - Supply (Max): 20mA
- Current - Output: 400mA
- Current - Quiescent (Iq): 2mA
- Voltage - Input (Max): 26V
- Base Part Number: LM2937
- Package / Case: TO-261-4, TO-261AA
- Voltage - Output (Max): -
- Output Configuration: Positive
- Series: -
- Supplier Device Package: SOT-223-4
- PSRR: -
- Part Status: Not For New Designs
- Mounting Type: Surface Mount
- Control Features: -
- Protection Features: Over Temperature, Reverse Polarity, Short Circuit
- Voltage - Output (Min/Fixed): 12V
- Number of Regulators: 1
- Packaging: Cut Tape (CT)
- detail: Linear Voltage Regulator IC 1 Output 400mA SOT-223-4
