دیتاشیت LM4120AIM5-3.3/NOPB

LM4120

مشخصات دیتاشیت

نام دیتاشیت LM4120
حجم فایل 1477.336 کیلوبایت
نوع فایل pdf
تعداد صفحات 27

دانلود دیتاشیت LM4120

LM4120 Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Voltage References
  • Datasheet: Texas Instruments LM4120AIM5-3.3/NOPB
  • Tolerance: ±0.2%
  • Output Type: Fixed
  • Input Voltage: 2V~12V
  • Output Current: 5mA
  • Output Voltage: 3.3V
  • Reference Type: series connection
  • Supply Current: 275uA
  • Noise - 10Hz to 10kHz: 36uVp-p
  • Operating Temperature: -40°C~+85°C@(Ta)
  • Noise - 1/10Hz to 10Hz: 20uVp-p
  • Temperature Coefficient: 50ppm/°C
  • Package: SOT-23-5
  • Manufacturer: Texas Instruments
  • Series: -
  • Package / Case: SC-74A, SOT-753
  • Current - Supply: 275µA
  • Current - Output: 5mA
  • Noise - 0.1Hz to 10Hz: 20µVp-p
  • Part Status: Not For New Designs
  • Mounting Type: Surface Mount
  • Voltage - Input: 2V ~ 12V
  • Voltage - Output (Min/Fixed): 3.3V
  • Packaging: Cut Tape (CT)
  • Base Part Number: LM4120
  • Supplier Device Package: SOT-23-5
  • detail: Series Voltage Reference IC ±0.2% SOT-23-5
