TPS7A7002DDAR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TPS7A7002DDAR
|
|
حجم فایل
|
85.778
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
21
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments TPS7A7002DDAR
-
Output Type:
Adjustable
-
Output Current:
3A
-
Output Voltage:
0.5V~5V
-
Dropout Voltage:
600mV@(3A)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
6.5V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
3mA
-
Power Supply Rejection Ratio (PSRR):
-
-
Package:
SOP-8-EP
-
Manufacturer:
Texas Instruments
-
Voltage - Output (Min/Fixed):
0.5V
-
Voltage Dropout (Max):
0.38V @ 2A
-
Package / Case:
8-PowerSOIC (0.154", 3.90mm Width)
-
Control Features:
Enable
-
Supplier Device Package:
8-SO PowerPad
-
Current - Output:
3A
-
Voltage - Output (Max):
5V
-
Packaging:
Cut Tape (CT)
-
Mounting Type:
Surface Mount
-
Part Status:
Active
-
Output Configuration:
Positive
-
Series:
-
-
Base Part Number:
TPS7A7
-
Voltage - Input (Max):
6.5V
-
Protection Features:
Over Current, Over Temperature, Under Voltage Lockout (UVLO)
-
PSRR:
-
-
Number of Regulators:
1
-
Current - Quiescent (Iq):
3mA
-
detail:
Linear Voltage Regulator IC 1 Output 3A 8-SO PowerPad
