دیتاشیت LM3488MM/NOPB
مشخصات دیتاشیت
| نام دیتاشیت | LM3488, LM3488-Q1 |
|---|---|
| حجم فایل | 1775.144 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 39 |
دانلود دیتاشیت LM3488, LM3488-Q1 |
LM3488, LM3488-Q1 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Controllers
- Function: boost converterType;Buck-boost type
- Topology: Boost;Flyback;SEPIC
- Datasheet: Texas Instruments LM3488MM/NOPB
- Input Voltage: 2.97V~40V
- Duty Cycle (Max): 100%
- Number of Outputs: 1
- Switching Frequency: 1MHz
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: NO
- Package: MSOP-8
- Manufacturer: Texas Instruments
- Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
- Control Features: Enable, Frequency Control
- Output Configuration: Positive
- Packaging: Cut Tape (CT)
- Supplier Device Package: 8-VSSOP
- Part Status: Active
- Base Part Number: LM3488
- Output Type: Transistor Driver
- Output Phases: 1
- Synchronous Rectifier: No
- Voltage - Supply (Vcc/Vdd): 2.97V ~ 40V
- Frequency - Switching: 100kHz ~ 1MHz
- Series: -
- Mounting Type: Surface Mount
- Clock Sync: Yes
- Serial Interfaces: -
- detail: Boost, Flyback, SEPIC Regulator Positive Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 8-VSSOP
